Additional information
| NTT product code | B203 |
|---|---|
| Tsubaki article no. | 5013002030 |
| Standard packaging | P |
| Mass [kg/m] | 0,23 |
| Dimension A Tolerance 006 0 | 25 |
| Dimension B Max Tolerance mm | –0,039 |
| Dimension B Min Tolerance mm | –0,014 |
| Dimension b mm | 40 |
| Dimension C Tolerance 0025 0 | 16,51 |
| Drag torque nm | 0,098 |
| Housing bore tolerance mm | +0 to +0,025 |
| Jis bearing number | 6203 |
| Max indexing cycle min | 150 |
| Max Overrunning Speed Inner RPM | 2400 |
| Max Overrunning Speed Outer RPM | 500 |
| Outer race keyway b p10 | 4 x 2,5 |
| Outer race keyway t1 | 4 x 2,5 |
| Torque capacity nm | 39,2 |
