Additional information
| NTT product code | MG400 |
|---|---|
| Tsubaki article no. | 5010040000 |
| Standard packaging | P |
| Mass [kg/m] | 2,7 |
| Bore size h7 mm | 22 |
| Dimension a mm | 70 |
| Dimension b h7 mm | 88 |
| Dimension c mm | 67 |
| Dimension d mm | 73 |
| Dimension e mm | 10,7 |
| Dimension f mm | 31,7 |
| Dimension s mm | 16 |
| Drag torque nm | 0,284 |
| H m tapped holes | 4 x M8 x P1,25 |
| Housing bore tolerance mm | +0 to +0,021 |
| Inner race keyway | 5 x 2 |
| Lubrication filter plug | M6 x P1,0 |
| Max Overrunning Speed Inner RPM | 2600 |
| Max Overrunning Speed Outer RPM | 800 |
| Oil cc | 30 |
| Torque capacity nm | 539 |
